• Measure voltage and current with your clamp jaw
• Faster, safer testing - all without touching a live wire - using FieldSense technology
• Complete 3-phase voltage and current tests in 3 quick steps
Specifications
• General Maximum Voltage between any Terminal and Earth Ground: 1000 V
• Battery Type: 2 AA IEC LR6 alkaline /& Life: 200 hour
• AC Current: Jaw
• Electrical
• Range: 999.9 A
• Resolution: 0.1 A
• Accuracy: 2 % ±5 digits (45 Hz to 66 Hz)
• Crest Factor: (50/60 Hz) 3 @ 500 A /& 2.5 @ 600 A /& 1.42 @ 1000 A /& Add 2 % for C.F. >2
• AC Current
• Range: 2500 A
• Resolution: 1 A (≤2500 A) 0.1 A (≤999.9 A)
• Accuracy: 3 % ±5 digits (5 Hz to 500 Hz)
• Crest Factor: (50/60Hz) 3.0 at 1100 A /& 2.5 at 1400 A /& 1.42 at 2500 A /& Add 2 % for C.F. >2
