PUMP:
• RKA +CR GEAR BOX (228) by AR.
• AR 3-piston alternating volumetric pump for use on cleaning units and industrial systems. Die-cast aluminum alloy pump body, pump head in pressed brass. Hardened and tempered steel pistons driven by connecting rods mechanical system with 1:2 reduction gear box to reduce the pump speed. Solid ceramic pistons. High temperature thermal relief protection. Automatic throttle speed control (decelerator).
ENGINE:
• HONDA GX390
• The GX390 engine is suitable for a wide range of heavy duty applications. OHV design enhances combustion efficiency. Easy starting with an automatic decompression system. Reduced fuel consumption and excellent exhaust emissions performance.
FRAME:
• Corrosion resistant steel frame equipped with convenient set of nozzles, trigger gun and lance holders. Integrated detergent tank (2,8l). Anti vibration foots for vibration and noise reduction. Inflatable tires.
Specifications
• Max Pressure [bar]: 280
• Max Pressure [psi]: 4060
• Flow Rate [l/h]: 960
• Flow Rate [gph]: 254
• Engine Power [HP]: 13,0
• Engine Power [kW]: 8,7
• Engine freq. [rpm]: 1750
• Engine kind: H
• Weight [Kg]: 64,0
