• Thermal overload protection: shuts down the power source output if the main transformer or rectifier overheats.
• Industrial dual-gear-driven system: features no-tool, quick-change reversible drive roll (0.8/1.0 mm) and an easy-to-set tension adjustment knob.
• Professional wire drive motor: withstands even the most demanding applications.
• Superior arc control technology: provides the operator with state-of-the-art welding performance on a wide variety of materials.
• Traditional tapped design (10 steps) and laminated inductor: provide a stable, smooth: arc for consistent weld quality.
• Ergonomic, easy-to-operate controls: simplify setup without minimizing features or welding performance.
• Adjustable run-in control: allows the operator to optimize arc starting with a variety of different wires.
• Adjustable burnback control: reduces wire stubbing, arc flaring and prevents wire burnback to protect contact tips.
Specifications:
• PROCESSES: MIG (GMAW), Flux Cored (FCAW).
• Amperage/ Voltage Ranges: 30–200 A, 15–21 V
• Rated Output: 200 A at 24 VDC, 20% duty cycle
• Amps Input at Rated Output, 230 V, 50/60 Hz: 34
• Max. OpenCircuit Voltage: 40 VDC
• Wire Type and Diameter Dimensions: Solid steel: 0.6–1.2 mm (.023–.045 in.), Stainless steel: 0.8–1.0 mm (.030–.040 in.), Aluminium: 0.8–1.2 mm (.030–.045 in.), Silicon bronze: 0.8–1.0 mm (.030–.040 in.), Flux-cored: 0.9–1.2 mm (.035–.045 in.)
