• Touch screen control system
• Internet enabled
• Tire gripping carriage
• Visible mechanical down stops
• Automatic slow lowering for placement on stands
• Auto-return in single and paired modes
• Original wireless system — tried and true technology
• WPLS Wide Military model features patented self-centering adjustable carriage
Specifications
• Lift Capacity Per Column 19,000 (8391kg)
• Height of Lift Unit 88-1/2 (2248mm)
• Width of Lift Unit 44-1/4 (1124mm)
• Length of Lift Unit 53-5/8 (1362mm)
• Maximum Lift Height (4) or more units 69 (1753mm)
• Maximum Lift Height (2 units Normal Mode) 32 (813mm)
• Min-Max Wheel Diameter 5-24-1/2 (127mm-623mm)
• Max Hydraulic System Operating Pressure 2,500 psi
• Lift speed (Max Load) 60 per Min
• Weight of Lift Unit 1,481 lbs (672kg)
• Footprint of Lift Unit 350 square inches
• Ground Pressure for each Lift (Max Load) 43.1 psi
• Turning Radius of Lift Unit 47 (1194mm)
• Operating Peak Power 4 hp
• Operating Voltage 24 VDC Nominal
• Charger Voltage Required 120 VAC @ 60Hz
• Charger Amps Required 2.5 Amps
